"One RCP to rule them all"
2 kanals universell RCP för alla typer kameror som helt är IP baserat och med fysiska knappar, rattar, touch kontroll samt OLED informationsdisplay.
Inbyggd Gateway (GWY) och kan ström matas via ett PoE+ RJ45 nätverk som kopplas till en kamera inteface (t.ex. Cy-CI0) eller direkt till en IP kamera/kameror.
The Cy-RCP-DOU is a universal remote control panel for up to two cameras.
IP-based, it is ideal for any kind of production (even for remote production) and features physical buttons, rather than a web interface. It has a slightly smaller form factor than regular remote controls but can be set in a frame to fit the standard RCP size, leaving space for accessories like a mini selection panel or a mini joystick.
To work efficiently, the system synchronises touch-down (and Tally) between the RCP and matrix: selecting a camera from the RCP also controls the matrix to switch the vision monitor and selecting another camera from the matrix panel also changes the displayed camera on the RCP.
Specialty cameras usually lack video processing features in various ways, meaning that often colour correction equipment are added for post-processing and frame sync. We’ve integrated these as well from our RCPs in a seamless blend of camera and post controls. So, whatever is available in the camera head is controlled there and what is missing (i.e. black balance, gamma) is done in the post-production phase by controlling the video corrector. The camera interface stays consistent from one camera to another, on one camera saturation might be applied in the head while on the next one, the same knob will control saturation on the video corrector.
The RCP is supported by the Cy-CI0 which from a simple RJ45 connection enables control of cameras, lenses and other accessories via RS232, RS422, RS485 and LANC serial protocols. Power is provided via PoE+ or separate AC adapter. Direct connection to IP cameras also possible.
Supported Functions
Cyanview’s RCP features much of the functionality found on broadcast CCU remotes.
- White balance Manual/AWB/ATW auto modes
- Black balance, ABB
- Master Black and Black Gamma
- Iris, Gain, ND filters
- Shutter, Clear Scan
- AUTO Iris, Auto Focus
- Saturation, Matrix, Multi-Matrix
- Knee, White Clip
- Detail, Coring, Skin Detail
- Denoise
- Tally display and GPIO input
- Full Camera OSD Menu Access and Navigation
- Touchscreen for Pan & Tilt or Gimbal control
- Auto/manual focus, Zoom when available
- Camera switching and Touch Down
- Scene files for all cameras, option to save all at once
- Custom Camera functions based on selected models
- Satus Information, IP addresses, remote connection
