D8 Plus



Increased safety, flexibility and efficient rigging for complex loads are the main features of D8 Plus chain hoists. ChainMaster first presented the concept to the Berufsgenossenschaft (institution for statutory accident insurance and prevention in the event industry) many years ago, and in 2004 a working group run by VPLT, the association of event technology companies, published the industry code of practice SR2.0 based on our innovation. The incorporation of a second brake and BGV C1-standard safety features into BGV D8 chain hoists resulted in a product that does without load additional securing. Sales show that the market clearly approves the concept, not just in Germany but all over the world.







Basic Features

  • Capacity 125  - 2500 kg
  • Climbing- or

    Standard Suspension

  • Direct- or Contactor Control
  • Light and compact Housing
  • Precise Chain Guide
  • 5-Pocket Chain Wheel
  • Textile Chain Bag
  • 2 DC Brakes
  • Patented Friction Clutch for Overload Protection



D8 Plus Electric Chain Hoists

Chain with 1 fall
Capacity Speed Falls Load chain in mm

DIN-5684-8

Weight w.o. chain Data/Sheets
125 kg 4 m/min 1 4 x 12 mm 15 kg on request
160 kg 4 m/min 1 4 x 12 mm 15 kg on request
250 kg 4 m/min 1 5,2 x 15 mm 21 kg on request
320 kg 4 m/min 1 5,2 x 15 mm 21 kg on request
500 kg 4 m/min 1 7 x 22 mm 27 kg on request
500 kg 8 m/min 1 7 x 22 mm 30 kg on request
750 kg 4 m/min 1 7 x 22 mm 27 kg on request
1000 kg 4 m/min 1 7,4 x 27 mm 27 kg on request
1250 kg 4 m/min 1 11 x 31 mm 80 kg  on request
1250 kg 8 m/min 1 11 x 31 mm  80 kg on request



(All data is approximate; we cannot accept any liability for errors and omissions, and we reserve the right to make changes.)



D8 Plus Electric Chain Hoists

Chain with 2 fall
Capacity Speed Falls Load chain in mm

DIN-5684-8

Weight w.o. chain Data/Sheets
250 kg 2 m/min 2 4 x 12 mm 15 kg on request
500 kg 2 m/min 2 5,2 x 15 mm 21 kg on request
1000 kg 2 m/min 2 7 x 22 mm 27 kg on request
1000 kg 4 m/min 2 7 x 22 mm 30 kg on request
2000 kg 2 m/min 2 9 x 27 mm 58 kg on request
2500 kg 2 m/min 2 11 x 31 mm 80 kg on request
2500 kg 4 m/min 2 11 x 31 mm 80 kg on request



(All data is approximate; we cannot accept any liability for errors and omissions, and we reserve the right to make changes.)







Ring oss för en offert!



Filtrera & sortera
Antal artiklar 19
Sortera
Visa per sida
Sida 1 av 2
ChainMaster Ultra 250Kg BGV-D8+ std telfer 4m/min, 12m
Pris exkl.20999
ChainMaster Ultra 250Kg BGV-D8+ std telfer 4m/min, 18m
Pris exkl.22757
ChainMaster Riggliftpaket SK 750Kg BGV-D8+  18m, sv-kätting, Fasstyrd
Pris exkl.31258
ChainMaster PK 1000Kg BGV-D8+ std telfer 4m/min, 18m
Pris exkl.35893
ChainMaster 250Kg BGV-D8+ std telfer 4m/min 18m Fasstyrd
Pris exkl.23591
ChainMaster 320Kg BGV-D8+ std telfer 4m/min 18m
Pris exkl.24327
ChainMaster 500Kg BGV-D8+ std telfer 4m/min 18m
Pris exkl.28512
ChainMaster SK 750Kg BGV-D8+ std telfer 4m/min 18m
Pris exkl.30943
Sida 1 av 2

Ladda ner ChainMaster katalog
